The ABB 5SHX1960L0004 is a premium original IGCT power electronic component engineered as the core switching device for ABB medium voltage industrial drives, specially tailored for ACS1000 and ACS2000 series medium-voltage frequency converters widely deployed in heavy-duty industrial fields. Developed with ABB’s decades of mature power semiconductor innovation, this component merges the robust overcurrent resistance of traditional thyristors and the fast switching performance of high-end IGBT chips, striking an ideal balance between high voltage endurance, low power loss and reliable dynamic operation. All units are original factory genuine products kept In Stock, with fast global shipping available to support emergency maintenance replacement and medium voltage drive retrofitting for steel mills, chemical plants, thermal power stations and underground mining projects worldwide. Strict full-process factory tests including high-voltage withstand, accelerated aging and short-circuit durability inspection are implemented for every finished component to comply with CE and UL international industrial safety specifications before shipment.

Detailed Electrical, Mechanical & Thermal Specifications

In core electrical parameters, its repetitive peak blocking voltage (VDRM) hits 6500V; rated continuous average on-state current reaches 1900A at 85℃ baseplate temperature under 180° conduction cycle, while maximum allowable instantaneous surge current peaks at 6000A to withstand equipment startup inrush and abrupt load current surges. The typical turn-off time is controlled within 1.2μs to support stable medium-frequency switching and reduce overall converter switching loss, lifting the comprehensive energy efficiency of matched medium voltage drives above 98%. It exclusively pairs with ABB original GDU 3BHL000390P0104 gate drive unit via fiber-optic signal transmission complying with IEC 60747-9 standard; fiber isolation completely separates high-power main circuit and low-voltage control circuit to restrain EMI interference, meanwhile feeding real-time overvoltage, overcurrent and overtemperature fault signals back to drive control system for instant protective locking. The matched gate drive requires ±15VDC auxiliary power supply from internal converter power source for stable triggering performance.
For mechanical and thermal indexes, the component adopts sealed flat ceramic packaging integrated with high-conductivity copper baseplate; overall dimension measures 190mm×140mm×40mm with net weight around 2.6kg, designed with bolt fastening structure to directly install on water-cooled heat sinks for efficient heat dissipation. Rated operating junction temperature ranges from -40℃ to +125℃, and storage temperature spans -55℃~+150℃, enabling steady long-term running under high-temperature, humid and dusty harsh on-site industrial environments of chemical workshops and open-air power plants. Built-in multi-layer hardware protection circuit automatically cuts off switching output upon short-circuit, overheat or abnormal DC bus voltage fluctuation to avoid permanent breakdown of drive power units.

Product Merits & Industrial Application Coverage

Benefiting from standardized modular construction, the component realizes quick on-site disassembly and replacement, drastically shortening unexpected production downtime during medium voltage drive malfunction maintenance. In steel manufacturing industry, it serves as core power unit of large rolling mill medium voltage inverters to implement stepless speed regulation of main rolling motors, optimizing finished steel processing precision and cutting factory power consumption effectively. Within petrochemical industry, it dominates variable-frequency control of high-power centrifugal compressors and large industrial process pumps to fulfill factory energy-saving transformation demands. Moreover, it is extensively configured on thermal power station induced draft fans, mine hoist medium voltage converters and grid-connected high-power rectifier equipment for new energy power plants.
With abundant original spot inventory, we arrange fast international delivery covering Asia, Europe, Middle East and Southeast Asia, satisfying global clients’ urgent spare part replenishment and medium voltage drive upgrading needs anytime. As the designated OEM replacement power electronic component for ABB medium voltage converters, 5SHX1960L0004 features ultra-low failure rate and long service lifespan, consistently remaining the mainstream preferred core semiconductor part in global medium voltage drive aftermarket.
