ABB HESG112802M14 / HESG324008 / HE502032-1735 / 216GW62

Product Overview

ABB HESG112802M14 (also marked HESG324008, HE502032-1735, 216GW62) is an IGCT gate drive unit, designed for ABB ACS6000 series medium voltage converters. This unit is responsible for triggering IGCT power semiconductor devices and monitoring the working status of the power stack.

It receives optical trigger signals from the main control board, converts optical signals into powerful gate drive pulses to turn on/off the IGCT. Meanwhile, it continuously monitors device current, voltage and fault status. Once abnormal conditions such as overcurrent occur, it immediately sends fault feedback via optical fiber to the controller for protection action. Optical isolation separates low voltage control circuits and high voltage power side to resist strong electromagnetic interference inside high-power converter cabinets. It is a critical discontinued spare component used for overhaul and repair of legacy ACS6000 medium voltage drives in heavy industrial sites.

Key Features

1. Part Markings: HESG112802M14, HESG324008, HE502032-1735, 216GW62 (different marking codes for same IGCT gate drive assembly)
2. Product Type: IGCT Gate Drive Unit for ABB medium voltage power stack
3. Optical fiber signal input for trigger command and fault feedback
4. High-current gate pulse output for IGCT turn-on / turn-off control
5. Built-in overcurrent, short-circuit and device fault detection
6. Complete optical galvanic isolation between control side and high-power stage
7. Onboard status LED indicators for quick on-site fault diagnosis
8. Optimized for continuous heavy-duty operation of high-power converters
9. Compact assembly, directly mounted on IGCT power stack
10. Obsolete original spare for legacy ACS6000 drive maintenance

Technical Specifications

Application Fields

ABB HESG112802M14 / HESG324008 / HE502032-1735 / 216GW62 gate drive unit serves heavy-industry medium voltage converter maintenance: ✅ Steel mill rolling mill ACS6000 medium voltage drive cabinet ✅ Mine hoist and heavy crusher high-power converter ✅ Large industrial fan and water pump medium variable speed control ✅ Cement rotary kiln medium voltage frequency converter ✅ Petrochemical large compressor drive unit ✅ Power plant auxiliary medium voltage converter overhaul and spare replacement

Matching Accessories

• IGCT power semiconductor module
• ACS6000 main control board & interface boards
• Optical fiber trigger cables
• Power stack snubber circuit components
• Other ACS6000 drive spare modules

Our Service

We supply original ABB HESG112802M14 / HESG324008 / HE502032-1735 / 216GW62 IGCT gate drive unit and full series ABB ACS6000 medium voltage drive spare parts. ✔ Limited ready stock for heavy industry drive maintenance ✔ Original part inspection and function testing ✔ Datasheet, wiring diagram and replacement guide available ✔ Technical support for power stack replacement, commissioning and troubleshooting ✔ Bulk quotation for metallurgy, mining and petrochemical maintenance contractors

Contact us for quotation, stock status and full datasheet of ABB HESG112802M14 / HESG324008 / HE502032-1735 / 216GW62.
