ABB DSDP140B 57160001-ACX

Product Overview

ABB DSDP140B, part number 57160001-ACX, is a high-speed counter board developed for ABB Advant Master DCS process control systemABB Group. It is a dedicated pulse acquisition module used to capture encoder pulses, frequency signals and high-speed digital events from field sensors.

This board counts pulses in real time and converts pulse signals into speed, position and flow data for the main controller. It is widely used for rotational speed detection and position tracking of motors and rotating machinery. It adopts standard rack plug-in structure, communicates with the Advant Master controller via backplane bus. It is an obsolete spare component, mainly used for overhaul, spare replacement and maintenance of old Advant Master control cabinets in power, pulp & paper and metallurgy industries.

Key Features

1. Model: DSDP140B, ABB Order Code: 57160001-ACX
2. Product Type: High-speed Counter Board, belongs to Advant Master DCS series
3. High-speed pulse and encoder signal acquisition, speed & position calculation
4. Multi-channel pulse input, support incremental encoder signal
5. Rack plug-in Eurocard design for easy installation and replacement
6. Onboard signal conditioning circuit, strong anti-interference performance
7. Status LED indicators for power and channel fault diagnosis
8. Communicate with Advant Master controller through rack backplane bus
9. Rugged PCB design, suitable for continuous 24/7 industrial cabinet operation
10. Discontinued original spare part for legacy DCS maintenance

Technical Specifications

Application Fields

ABB DSDP140B 57160001-ACX counter board is deployed for legacy Advant Master DCS maintenance: ✅ Pulp and paper mill production line speed and position monitoring ✅ Thermal power plant auxiliary rotating equipment measurement ✅ Metallurgy rolling line encoder pulse acquisition ✅ Conveyor belt speed and flow monitoring system ✅ Legacy Advant Master control cabinet overhaul and spare replacement ✅ Heavy industry process control retrofit projects

Matching Accessories

• Advant Master controller rack and backplane
• Encoder signal cables and terminal blocks
• Advant Master CPU and communication boards
• Signal termination units
• Other Advant Master series I/O modules

Our Service

We supply original ABB DSDP140B (57160001-ACX) counter board and full range ABB Advant Master DCS spare parts. ✔ Limited ready stock for legacy DCS maintenance ✔ Original part inspection and function testing ✔ Datasheet, wiring diagram and replacement guide available ✔ Technical support for module replacement, commissioning and troubleshooting ✔ Bulk quotation for plant maintenance contractors

Contact us for quotation, stock status and full datasheet of ABB DSDP140B 57160001-ACX.
