ABB PDD200A101

Product Overview

ABB PDD200A101, part number 3BHE019633R0101, is a power distribution and gate driver interface module designed for ABB UNITROL6000 generator excitation system and ACS6000 medium voltage drive converter platforms. It supplies regulated multi-channel isolated auxiliary power for gate drive units, monitors gate trigger signals and power unit operating status. This module serves as the power and signal bridge between the rack backplane and IGCT/IGBT power stacks. Reinforced galvanic isolation protects low-voltage control circuits from high voltage surges and strong electromagnetic interference inside high-power cabinets. It is widely used for spare replacement, overhaul and retrofit of power plant excitation cabinets and heavy-duty medium voltage drive systems.

Key Features

1. Part No: 3BHE019633R0101, Model: PDD200A101 Power Distribution & Gate Driver Interface Module
2. Compatible Platform: ABB UNITROL6000 Excitation, ACS6000 Medium Voltage Drive, AC800PEC
3. Provide multiple isolated regulated auxiliary power rails for gate driver units
4. Real-time supervision of gate trigger signals and power unit fault feedback
5. Reinforced galvanic isolation between control side and high-power stage
6. Rack plug-in Eurocard design for quick replacement
7. Built-in status & fault LED indicators for fast on-site diagnosis
8. High anti-EMI capability for noisy high-power converter cabinet environment
9. Continuous heavy-duty operation for generator excitation and large motor drives
10. Original spare part for power plant and metallurgy high-power equipment maintenance

Technical Specifications

Application Fields

ABB PDD200A101 module is widely used for high-power converter and excitation cabinet maintenance: ✅ Thermal / Hydropower plant UNITROL6000 generator excitation system ✅ Steel mill ACS6000 medium voltage drive for rolling mill ✅ Mine hoist, large crusher medium voltage converter cabinet ✅ Petrochemical large compressor high-power variable speed drive ✅ Cement rotary kiln medium voltage frequency converter ✅ Power station auxiliary drive system overhaul & spare replacement ✅ Heavy industrial power electronics retrofit project

Matching Accessories

• IGCT power stacks and gate drive boards
• UNITROL6000 / ACS6000 control rack & backplane
• Optical fiber trigger cables
• Signal wiring harness and terminal connectors
• Other UNITROL / ACS6000 series spare modules

Our Service

We supply original ABB PDD200A101 (3BHE019633R0101) power distribution module and full range ABB UNITROL & ACS6000 medium voltage drive spare parts. ✔ Ready stock for power plant & heavy industry maintenance ✔ Original part inspection and function testing ✔ Datasheet, wiring diagram and replacement guide available ✔ Technical support for module replacement, troubleshooting and commissioning ✔ Bulk quotation for power station EPC and industrial maintenance contractors

Contact us for quotation, stock status and full datasheet of ABB PDD200A101.
