ABB 5SHX1960L0004 Medium Voltage IGCT Power Module | Original In Stock, Fast Global Delivery

Product Overview

The ABB 5SHX1960L0004 (part code: 3BHL000390P0104) is a high-power IGCT (Integrated Gate Commutated Thyristor) medium voltage power module (often referred to as medium voltage IGBT module), belonging to ABB classic 5SHX high-performance power electronic series. It is the core power switching component for medium voltage frequency converters, high-power inverter systems, industrial drives and power transmission equipment. Manufactured strictly to ABB original industrial standards, every unit undergoes full load aging testing, high voltage withstand testing, EMC electromagnetic compatibility testing and thermal cycling durability testing before factory release. We stock 100% brand-new original genuine units locally, support expedited global shipping worldwide, and provide a standard 12-month manufacturer warranty, ideal for new medium voltage project configuration, drive cabinet overhaul and emergency rush maintenance replacement for heavy industry power systems。Core Technical Specifications

表格

Item	Parameter
Rated Voltage	6000V
Rated Current	1960A
Max Switching Frequency	10kHz
Working Temperature	-40℃ ~ +85℃
Storage Temperature	-40℃ ~ +85℃
Overall Dimension	335mm×250mm×120mm
Net Weight	15kg
Protection Grade	IP65
Trigger Mode	Fiber Optic Light Triggering
Cooling Method	Forced Air Cooling
Core Technology	Press-pack chip packaging, multi-chip parallel current sharing design

Key Original ABB Performance Advantages

1. Ultra High Voltage & Large Current Bearing Capacity Specially designed for medium voltage industrial power scenarios, it stably bears 6000V high voltage and 1960A large rated current, perfectly matching 2.3kV / 3.3kV / 4.16kV medium voltage drive systems. The press-pack sealed packaging realizes excellent current equalization performance, supporting stable long-term full-load operation under heavy impact loads in mining, metallurgy and power plants。
2. Fiber Optic Light Triggering, Strong Anti-Interference Performance Adopts optical fiber isolated signal transmission for gate control, completely isolating strong electrical interference from the power main circuit. It delivers precise nanosecond-level switching response, effectively resisting harmonic interference, voltage surge and electromagnetic noise in complex industrial power grids, greatly improving system operation stability in harsh electrical environments。
3. Built-in Comprehensive Multi-Layer Safety Protection Integrates real-time junction temperature monitoring, overcurrent protection, overvoltage protection, RC absorption circuit and soft shutdown logic. When overtemperature, short-circuit or overload faults occur, the module triggers intelligent limiting shutdown instantly to avoid thermal runaway and permanent burnout of internal chips, fully safeguarding the whole medium voltage drive system and upstream/downstream electrical equipment。
4. High Energy Conversion Efficiency & Excellent Thermal Stability Optimized internal chip layout and high-efficiency heat conduction structure reduce conduction and switching loss remarkably, boosting overall system energy efficiency and lowering operating power consumption. The wide temperature range design ensures stable performance under continuous 24/7 unattended operation in high-temperature factory electrical rooms and low-temperature field environments, with outstanding long MTBF reliability。

Main Industrial Application Scenarios

Widely applied in core medium voltage power equipment across global heavy process industries:

• Medium voltage frequency converters for metallurgical rolling mills, mine hoists, large conveyor systems
• High-power wind power converters, photovoltaic grid-connected inverters and new energy power generation equipment
• Thermal power plant auxiliary medium voltage drives, high-voltage direct current (HVDC) transmission systems
• Large water pump/fan energy-saving variable speed drives, industrial high-power welding and heating power supplies
• Complete ABB medium voltage drive cabinet matching and original system spare replacement projects。

Wide Environmental Adaptability & International Certifications

It passes strict vibration, mechanical shock and damp-heat aging testing, runs reliably in dusty metallurgical workshops, humid coastal chemical bases, alpine low-temperature industrial sites and offshore power platforms. Fully certified with CE, UL, IEC international industrial electrical safety standards, all original modules carry exclusive serial numbers and production batch codes for full-lifecycle original ABB quality traceability, far superior to generic aftermarket power modules in stability and service life.

Original In-Stock Supply & Global Fast Shipping Service

All supplied ABB 5SHX1960L0004 IGCT modules are 100% brand new authentic original ABB factory products, complete with official sealed original packaging and full factory performance test reports, covered by a formal 12-month warranty for manufacturing defects under rated operating conditions. Our warehouse maintains sufficient permanent ready stock to rapidly fulfill urgent maintenance orders and large-volume bulk procurement for international medium voltage EPC projects. We adopt professional anti-static, shockproof and moisture-proof dedicated export packaging to protect precision power chips during long-distance sea and air international transportation. We cooperate with DHL, FedEx, UPS and other mainstream global logistics providers to deliver fast worldwide shipment covering Europe, North America, Southeast Asia, the Middle East and other major industrial regions, with professional coordinated customs clearance support. Our full service includes pre-sales parameter matching verification, drive system scheme consultation, plus after-sales technical support including installation guidance, cooling system commissioning and power circuit debugging.
Selecting the original ABB 5SHX1960L0004 medium voltage IGCT module delivers high-efficiency, safe and stable core power guarantee for your medium voltage drive and industrial power automation systems. Original ABB power semiconductor manufacturing technology fully meets the rigorous reliability requirements of heavy industry continuous production, effectively cutting unplanned downtime risks and long-term maintenance costs. Combined with our efficient global fast delivery and complete warranty protection, it provides indispensable original hardware support for safe, energy-saving and stable operation of metallurgy, power, mining and new energy medium voltage power facilities worldwide.
