ABB 5SHX1960L0004 High-Power IGCT Power Module | Dedicated for Industrial Medium Voltage Drive Applications

Product Introduction

The ABB 5SHX1960L0004 is a professional press-pack IGCT (Integrated Gate Commutated Thyristor) power module, the core power switching component designed exclusively for ABB medium voltage industrial drive systems. Widely applied on heavy-duty medium voltage inverters, high-power motor drives and industrial frequency conversion equipment in mining, metallurgy, power, cement and petrochemical industries, it undertakes AC/DC power conversion and precise speed regulation for large industrial motors. Produced fully in accordance with ABB original power semiconductor manufacturing standards, each module undergoes high voltage withstand testing, full-load aging testing, optical trigger performance testing and EMC anti-interference testing before factory delivery. We provide 100% brand new original genuine stock, global fast delivery and a standard 12-month warranty, ideal for new drive project assembly, inverter overhaul and emergency spare replacement of industrial drive equipment.

Key Technical Specifications

• Model: 5SHX1960L0004
• Rated repetitive peak off-state voltage: 6500V
• Continuous nominal current: 1960A
• Surge withstand peak current: 6000A
• Trigger method: Fiber optic isolated gate triggering (matched dedicated GDU gate drive unit)
• Package type: Press-pack disc pressure contact packaging
• Operating temperature range: -40℃ ~ +85℃
• Cooling mode: Forced air cooling / water cooling
• Matching drive system: ABB ACS1000 / ACS2000 series medium voltage drives

Core Advantages for Industrial Drive Systems

1. High Voltage & Large Current Bearing Capacity for Heavy-Duty Drives

Adopts multi-chip parallel current-sharing press-pack packaging technology, supporting stable long-term full-load operation under 6500V high voltage and 1960A large current. It perfectly adapts to 3kV-class medium voltage drive working conditions, can withstand frequent impact loads from mine hoists, metallurgical rolling mills, large belt conveyors and kiln main motors. Excellent current equalization performance effectively avoids local overheating and chip damage under heavy startup and overload conditions, fully meeting the harsh load requirements of industrial drive equipment.

2. Fiber Optic Isolated Trigger, Superior Anti-Interference Performance

Optical fiber signal completely isolates the low-voltage control circuit and high-voltage power main circuit, effectively resisting grid harmonic distortion, voltage surges and strong electromagnetic interference on industrial sites. The switching response is fast and precise, ensuring the upper control system sends speed regulation, start-stop and protection commands to be executed accurately without signal distortion or delay. It fundamentally avoids drive operation disorder caused by electrical interference, greatly improving the stable running performance of the complete drive system.

3. Comprehensive Built-in Protection to Secure Drive Operation

Integrates real-time junction temperature monitoring, overcurrent protection, overvoltage clamping, short-circuit lockout and intelligent soft shutdown logic. Once overload, short circuit, over-temperature and other faults occur during drive operation, the module will quickly implement power limiting protection to prevent thermal runaway and permanent burnout of internal chips. It can effectively protect the main inverter cabinet, control unit and high-power driven motor, realizing perfect safety protection for the whole industrial drive chain.

4. Low Power Loss & Excellent Thermal Stability for Long-Time Continuous Operation

Optimized internal chip layout reduces conduction loss and switching loss significantly, improving the overall energy efficiency of medium voltage drives and lowering long-term operating electricity costs. The press-fit structure delivers outstanding thermal conductivity, cooperating with the drive cabinet cooling system to achieve efficient heat dissipation. It can run stably for 24/7 unattended continuous production, with excellent MTBF indicators and long service life suitable for non-stop industrial production lines.

Main Industrial Drive Application Scenarios

1. Metallurgy & Mining Drives: Medium voltage inverters for rolling mill main drives, mine hoist control systems, long-distance heavy conveyor drive equipment
2. Power Plant Auxiliary Drives: Energy-saving variable frequency drives for large induced draft fans, forced draft fans and circulating water pumps in thermal power stations
3. Cement & Petrochemical Drives: Cement rotary kiln main drive inverters, large compressor, centrifugal pump medium voltage speed control systems
4. New Energy & Power Transmission: Wind turbine full-power converters, photovoltaic grid-connected inverters, SVC static reactive power compensation devices and high-power rectifier drives

Environmental Performance & International Certification

The module passes strict vibration, mechanical shock and damp-heat aging tests, adapting to dusty heavy industrial workshops, humid coastal chemical plants, low-temperature alpine industrial areas and outdoor power station environments. It complies with CE, UL, IEC international industrial electrical safety standards. Each original module is printed with a unique serial number and production batch code for full-lifecycle original quality traceability, with far better stability and durability than generic aftermarket power modules.

Original In-Stock Supply & Global Complete Service

All ABB 5SHX1960L0004 power modules we supply are 100% genuine original ABB factory products, equipped with complete original sealed packaging and official factory performance test reports, covered by a standard 12-month warranty against manufacturing defects under rated operating conditions. Our warehouse has abundant ready stock to quickly fulfill urgent drive maintenance orders and large bulk procurement for global industrial EPC projects. We adopt professional anti-static, shockproof and moisture-proof export packaging to protect precision semiconductor chips during long-distance sea and air international transportation. We cooperate with mainstream global logistics providers to realize fast worldwide delivery covering Europe, North America, Southeast Asia, the Middle East and other major industrial regions, with professional customs clearance support. Our full service includes pre-sales drive model parameter matching verification, system configuration consultation, as well as after-sales technical support including installation guidance, cooling system commissioning and inverter power circuit debugging.
Selecting the original ABB 5SHX1960L0004 power module provides reliable core power guarantee for your medium voltage industrial drive equipment. Original ABB semiconductor technology fully matches the long-term heavy-load operation requirements of industrial drive applications, reducing unplanned shutdown risks and later maintenance costs. Combined with our efficient global fast delivery and complete warranty service, it is the optimal original spare and configuration component for medium voltage industrial drive projects and equipment maintenance worldwide.
