ABB 5SHX1960L0004 High-Power IGCT Module (Commonly Named MV IGBT On Site) For Industrial Power Conversion Systems

Product Introduction

The ABB 5SHX1960L0004 is a high-performance press-pack IGCT power semiconductor module, the core power switching device specially designed for medium voltage power conversion systems, widely used in ABB ACS1000/ACS2000 medium voltage inverters, rectifier stations, new energy grid-connected converters, SVC reactive compensation and high-power industrial power conversion equipment. It undertakes high-efficiency AC/DC and DC/AC energy conversion for heavy industrial power scenarios. Manufactured strictly according to ABB original industrial semiconductor standards, every finished product passes high voltage withstand test, full-load aging test, fiber optical trigger precision test and EMC anti-electromagnetic interference test before delivery. We provide 100% brand-new original genuine products, abundant in-stock inventory, fast global delivery and a standard 12-month manufacturer warranty, perfectly suited for new power conversion project assembly, equipment overhaul and emergency spare part replacement worldwide.

Main Technical Parameters

• Model: 5SHX1960L0004
• Rated repetitive peak off-state voltage: 6500V
• Continuous rated on-state current: 1960A
• Max allowable surge peak current: 6000A
• Drive mode: Fiber optic isolated gate triggering (matched with dedicated GDU gate drive unit)
• Package form: Press-pack disc pressure contact packaging
• Operating temperature range: -40℃ ~ +85℃
• Applicable cooling: Forced air cooling / water cooling
• Applicable system voltage: 3kV-class medium voltage power conversion platform

Core Advantages for Power Conversion Systems

1. Super High Voltage & Large Current Load Capacity

It adopts mature multi-chip parallel current-sharing press-pack technology, which can run stably under long-term full load of 6500V high voltage and 1960A large current. The internal chips achieve excellent current balance performance, which can withstand instantaneous surge current and heavy impact loads during rectification, inversion and energy feedback processes. It fully meets the rigorous heavy-load operation requirements of metallurgy, mining, power generation and other high-power conversion occasions, and effectively avoids local overheating and chip damage caused by uneven current distribution.

2. Fiber Optic Isolation Trigger, Excellent Anti-Interference Performance

The optical fiber control signal completely isolates the low-voltage control circuit from the high-voltage power main circuit, which can effectively resist grid harmonic distortion, voltage surges, lightning impact and strong electromagnetic noise in complex power station environments. It features microsecond-level fast switching response, ensuring that PWM control instructions issued by the upper controller are executed accurately without signal delay or mis-triggering, greatly improving the overall stability and safety of the power conversion system.

3. Comprehensive Multi-layer Safety Protection

Built-in real-time junction temperature monitoring, overcurrent protection, overvoltage clamping, short-circuit locking and intelligent soft shutdown logic. Once abnormal conditions such as short circuit, overload and overtemperature occur during power conversion operation, the module will immediately perform power limiting protection to prevent chip thermal runaway and permanent burnout. It can fully protect the front-end rectifier cabinet, rear inverter equipment, transformers and supporting electrical equipment to realize full-loop safety interlock for the power conversion system.

4. Low Power Loss & Outstanding Thermal Stability for Continuous Operation

The optimized internal chip layout significantly reduces conduction loss and switching loss during frequent power conversion, effectively improving the overall energy conversion efficiency of the system and reducing long-term operating power consumption. The press-fit structure has ultra-high thermal conductivity, which can perfectly cooperate with the cabinet cooling system to realize efficient heat dissipation. It supports 24/7 unattended continuous operation in power plants, new energy bases and heavy industrial workshops, with excellent MTBF reliability and long service life.

Typical Application Fields of Power Conversion

1. Medium Voltage Drive Conversion Systems: Core power unit of ACS series medium voltage inverters, used for rolling mill main drive, mine hoist, large fan and water pump frequency conversion speed regulation;
2. New Energy Power Conversion: Full-power converters for wind turbines, photovoltaic grid-connected inverters, bidirectional DC/AC conversion equipment for energy storage systems;
3. Power Grid Quality Control Conversion: SVC static reactive power compensator, SVG active power filter, high-power industrial electrolysis rectifier power supply system;
4. High-power Transmission Conversion: Auxiliary conversion equipment for HVDC transmission, industrial high-power heating and welding dedicated power conversion platforms.

Environmental Adaptability & International Certification

The module has passed strict vibration, mechanical shock and damp-heat aging tests, and can operate reliably in dusty heavy industrial workshops, humid coastal power stations, low-temperature alpine power bases and outdoor converter stations. It complies with CE, UL, IEC62477 international industrial electrical safety standards. Each original module is printed with a unique serial number and production batch code to realize full-lifecycle original ABB quality traceability, with far superior stability and service life compared with generic aftermarket imitation power modules.

Original In-Stock Supply, 12 Months Warranty & Global Fast Shipping

All ABB 5SHX1960L0004 power modules we supply are 100% genuine original ABB factory products, equipped with complete sealed original factory packaging and official factory full-performance test reports, covered by a formal 12-month warranty for manufacturing defects under rated normal operating conditions. Our warehouse has sufficient permanent ready stock to quickly respond to urgent maintenance orders of power conversion equipment and bulk procurement of global EPC power engineering projects. We use professional anti-static, shockproof and moisture-proof export packaging to protect precision semiconductor chips during long-distance sea and air international transportation. We cooperate with mainstream international logistics providers to realize fast delivery worldwide covering Europe, North America, Southeast Asia, the Middle East and other major industrial regions, with professional customs clearance coordination support. Our full service includes pre-sales power system parameter matching verification, conversion scheme technical consultation, as well as after-sales technical support including installation guidance, cooling system commissioning and power conversion circuit debugging.
Choosing the original ABB 5SHX1960L0004 high-power module can provide stable, efficient and safe core power support for your medium voltage power conversion systems. Original ABB power semiconductor technology perfectly adapts to continuous heavy-load conversion working conditions, effectively reducing unplanned system downtime and long-term maintenance costs. Coupled with our efficient global fast delivery and complete warranty protection, it is the preferred original core component for global power conversion system project construction and daily equipment maintenance.
