Product Overview

ABB P3EA is a compact industrial gauge pressure transmitter from ABB P-300 instrumentation series, a high-stability pressure sensor designed for process automation pipelines, tanks and pressure vessels. It converts fluid pressure (gas, liquid, steam) into standard analog/digital signals, realizing real-time pressure monitoring, flow/liquid level calculation and overpressure safety interlock for DCS/PLC control systems. We supply 100% brand-new genuine original ABB P3EA transmitters with full spot inventory, expedited worldwide delivery and standard 12-month factory warranty, widely used for new production line instrumentation configuration, old sensor replacement and emergency spare inventory for chemical, power, metallurgy and water treatment industries.

ABB Pressure Transmitter On-site Installation

Core Technical Specifications

表格

Parameter Item	Standard Specification
Model Series	P3EA (P-300 Compact Gauge Pressure Transmitter)
Measurement Type	Gauge Pressure
Measuring Range	0.05 kPa ~ 60 MPa (0.5 mbar ~ 600 bar), customizable small/large spans
Overpressure Limit	Max 90 MPa (900 bar) overvoltage protection
Measuring Accuracy	±0.055% FS ultra-high precision
Standard Output Signal	4–20mA analog; optional HART / PROFIBUS PA digital bus
Power Supply	12–30 VDC two-wire loop power supply
Wetted Material	316L stainless steel, optional Hastelloy for corrosive media
Ambient Temperature Range	-40 ℃ ~ +85 ℃ wide industrial temperature range
Protection Grade	IP67, NEMA 4X dustproof & waterproof
Explosion Certification	ATEX / IECEx Ex ia IIC T6 intrinsically safe for hazardous zones
Process Connection	Standard G1/2, 1/2NPT thread, matched manifold diaphragm seal optional
Optional Function	Local LCD backlight display, digital advanced diagnostic (DAD), plug impulse line detection
Certifications	CE, UL, SIL2 functional safety, NACE anti-sulfur standard

Core Advantages as Industrial Pressure Sensor

1. Ultra-High Precision & Stable Long-Term Measurement

Adopts ABB monocrystalline silicon piezoresistive sensing core with temperature self-compensation algorithm. Full-span accuracy up to 0.055%, tiny zero drift under wide temperature fluctuation, effectively eliminating pressure measurement deviation caused by workshop environment change. Supports continuous 24/7 monitoring of reactor, boiler and pipeline pressure without frequent calibration.

2. IP67 Rugged Housing & Anti-Corrosion Media Compatibility

Integrated all-welded stainless steel casing reaches IP67 protection, resisting dust, water splash, oil mist and condensation in harsh workshops. Multiple wetted material options: standard 316L stainless steel for water/oil medium; Hastelloy diaphragm for acid, alkali, hydrogen sulfide and other corrosive chemical fluids, adapting to complex process medium requirements of petrochemical plants.

3. Multi-Signal Output Flexible DCS System Matching

Supports universal 4–20mA two-wire analog signal compatible with all mainstream ABB AC800M, System 800xA DCS and third-party PLC; optional HART/PROFIBUS PA digital communication for remote parameter modification, data upload and equipment diagnosis. Built-in QR digital diagnosis function, scan to quickly view product manuals, fault codes and maintenance guides, greatly simplifying on-site debugging.

4. Built-In Predictive Maintenance & Pipeline Blockage Detection

Standard plug impulse line detection function automatically judges blockage of pressure guiding pipeline, sends early warning signals to control system in advance to avoid measurement failure and production safety hazards. Independent local zero adjustment button supports on-site quick zero calibration without professional debugging tools, lowering maintenance difficulty for field technicians.

5. Intrinsically Safe Explosion-Proof Design for Hazardous Areas

Passed ATEX/IECEx Ex ia IIC T6 intrinsically safe certification, can be directly installed in Zone 0/1 explosive gas dangerous areas such as oil depots, chemical reactors and hydrogen production workshops, fully complying with industrial explosion safety specifications. SIL2 safety certification supports safety instrumented system (SIS) overpressure interlock protection.

Main Industrial Application Scenarios

1. Thermal & Hydropower Plants: Boiler steam/water pipeline pressure monitoring, water supply pump outlet pressure, turbine auxiliary oil pressure measurement
2. Chemical & Petrochemical Industry: Reactor tank internal pressure, distillation tower pipeline pressure, flammable liquid storage tank pressure monitoring
3. Metallurgy & Heat Treatment: Furnace cooling water pressure, hydraulic station pressure, rolling mill lubricating oil pressure closed-loop control
4. Cement & Building Material Production: Rotary kiln wind pressure, raw material conveying pipeline pressure, dust removal system gas pressure detection
5. Water Treatment & Environmental Protection: Sewage pump outlet pressure, filter tank differential pressure, chemical dosing pipeline pressure monitoring
6. Oil & Gas Industry: Onshore pipeline transmission pressure, tank farm storage pressure, wellhead auxiliary pressure measurement

Original In-Stock & Global Fast Shipping Service

All ABB P3EA industrial pressure transmitters we provide are 100% genuine original factory products, equipped with complete sealed original packaging, factory calibration certificates and full-performance test reports, covered by a formal 12-month warranty against manufacturing defects under rated standard operating conditions. Our warehouse maintains abundant permanent ready stock to rapidly fulfill urgent instrument maintenance orders and bulk procurement for global industrial EPC projects. We adopt professional shockproof, moisture-proof and anti-static export packaging to protect precision sensor cores during long-distance sea and air international transportation. We cooperate with mainstream global logistics carriers to deliver fast worldwide shipment covering Europe, North America, Southeast Asia, the Middle East and all major process industrial regions, with one-stop professional customs clearance coordination support. Our full supporting service includes pre-sales pressure range & wetted material matching consultation, DCS/HART communication parameter configuration guidance, plus after-sales on-site installation, zero calibration and complete process measurement system commissioning.
Selecting genuine original ABB P3EA pressure transmitter delivers ultra-stable high-precision pressure detection and comprehensive safety protection guarantee for your industrial DCS/PLC automation systems. Consistent original ABB instrumentation quality eliminates measurement drift, pipeline blockage blind spot and explosion safety risks brought by counterfeit pressure sensors, effectively reducing unplanned production line shutdown frequency and long-term instrument maintenance costs. Supported by our ample in-stock inventory, efficient fast worldwide shipping and complete 12-month warranty protection, it is the trusted original pressure sensor spare component choice for global process industrial automation projects.
