ABB PFCL201C10KN is a vertical force PillowBlock tension load cell from ABB Pressductor series, rated 10kN nominal measuring range, specially designed for vertical strip tension detection on metal rolling, coating, paper, film and lithium electrode production lines. It adopts integrated stainless steel monoblock strain gauge sensing structure, converts vertical roll bearing load into high-precision strain signal, matched with ABB PFEA111/PFEA112 tension amplifier to realize closed-loop constant tension control, effectively preventing strip wrinkling, stretching or breakage during unwinding, winding and slitting processes. We supply 100% brand-new genuine original Swedish ABB load cells with full spot inventory, expedited worldwide delivery and standard 12-month manufacturer warranty, widely used for production line retrofits, new equipment assembly and emergency spare replacement.

Core Technical Specifications

表格

Parameter Item	Standard Specification
Full Model	PFCL201C10KN
Nominal Rated Load	10 kN (2250 lbs) vertical measuring force
Extended Safe Load	15 kN (150% FS, full precision retained)
Max Vertical Overload Resistance	50 kN shock overload tolerance
Transverse Allowable Side Force	2.5 kN anti-offset impact capacity
Measuring Precision	≤ ±0.1% full scale high linearity
Sensing Technology	Pressductor patented magnetic strain gauge, no drift long-term stable
Housing Material	Integral machined 304 stainless steel, fully potted internal circuit
Protection Grade	IP65 dustproof, waterproof and anti-oil mist
Operating Temperature	-20 ℃ ~ +70 ℃ wide workshop temperature range
Storage Temperature	-40 ℃ ~ +85 ℃
Dimension	220 × 125 × 50 mm
Net Weight	2.1 kg
Matching Tension Amplifier	PFEA111 / PFEA112
Certifications	CE, industrial mill-duty heavy load certification

Core Advantages as Industrial Tension Measuring Component

1. Vertical Force Exclusive Design Optimized for Strip Production

PFCL201 series measures vertical bearing load of tension roller, independent of roller self-weight interference, higher measuring accuracy than horizontal PFTL201 load cellsABB Group. Ultra-high rigidity structure resists instantaneous impact during line acceleration/deceleration, suitable for high-speed continuous rolling and coating lines.

2. Super Strong Overload & Shock Resistance for Harsh Mill Environments

Single-piece stainless steel integral forming, withstands 50kN vertical impact overload and transverse offset force, avoiding sensor damage caused by strip breakage or mechanical collision. Fully sealed potting circuit resists acid mist, cooling water splash and metal dust in pickling, galvanizing and cold rolling workshops, long service life without regular calibration.

3. Patented Pressductor Sensing Low Zero Drift

ABB exclusive magnetic strain gauge technology eliminates creep and temperature drift defects of traditional resistance strain sensors, stable measurement output under continuous 24/7 full-load operation, greatly reducing periodic calibration frequency and maintenance labor cost.

4. Simple Matching & Seamless ABB Automation System Connection

Output standard strain signal compatible with ABB dedicated tension amplifiers, amplified 4–20mA analog signal can be directly connected to AC800M, System 800xA DCS and tension controllers, realizing real-time tension display, automatic speed adjustment and material breakage alarm closed-loop control.

5. Compact PillowBlock Pillow Bearing Base Easy On-Site Installation

Standard integrated pillow block mounting structure, directly installed on both ends of tension roller bearing seats without extra conversion brackets. Unified wiring connector, simple wiring and quick replacement, drastically shortening production line downtime during sensor maintenance.

Main Industrial Application Scenarios

1. Metallurgical Metal Strip Lines: Cold rolling, hot rolling, galvanizing, pickling, copper/aluminum foil slitting tension monitoring
2. Paper & Printing Industry: High-speed paper machines, coating printing, film slitting constant tension control
3. New Energy Lithium Battery Production: Electrode coating, separator slitting tension detection to guarantee battery consistency
4. Plastic & Packaging Industry: BOPET film, plastic bag making, composite coating unwinding/winding tension control
5. Textile & Non-Woven Lines: High-speed textile cloth, non-woven fabric anti-wrinkle tension closed-loop regulation

Original In-Stock & Global Fast Shipping Service

All ABB PFCL201C10KN vertical tension load cells we provide are 100% genuine original factory products, equipped with sealed original packaging, factory calibration certificates and complete performance test reports, covered by a formal 12-month warranty against manufacturing defects under rated operating conditions. Our warehouse holds abundant permanent ready stock to rapidly process urgent production line maintenance orders and bulk procurement for global industrial EPC projects. We adopt professional shockproof, moisture-proof and anti-static export packaging to protect precision sensing cores during long-distance sea and air international transportation. We cooperate with mainstream global logistics carriers to deliver fast worldwide shipment covering Europe, North America, Southeast Asia, the Middle East and all major process industrial regions, with one-stop professional customs clearance support. Our supporting services include pre-sales load range selection consultation, PFEA amplifier matching scheme design, plus after-sales roller bearing seat installation guidance, tension signal calibration and full production line tension control system overall commissioning.
Selecting genuine original ABB PFCL201C10KN tension load cell delivers ultra-stable high-precision vertical strip tension detection and strong anti-impact protection guarantee for your metal, new energy and paper film industrial automation production lines. Consistent original ABB mill-grade quality eliminates measurement drift, overload burnout and tension control deviation risks brought by counterfeit sensors, effectively reducing unplanned production line shutdown frequency and long-term equipment maintenance costs. Supported by our ample in-stock inventory, efficient fast worldwide shipping and complete 12-month warranty protection, it is the trusted original vertical tension measuring spare component choice for global strip processing automation projects.
