• Model: LXN1604-6
• Part No.: 3BHL000986P7000
• Brand: ABB Original New
• Series: ABB Convert Select, matched for ABB Ability™ System 800xA industrial control system
• Type: DIN rail mounted industrial switching power supply module

2. Core Electrical Specifications

• Input Range: 85–264 VAC / 90–350 VDC universal wide input
• Rated Output: 24.7 VDC, 20 A, total power 500 W
• Conversion Efficiency: ≥90%, low heat loss, built-in energy-saving standby mode
• Isolation: 3kV AC reinforced isolation between input & output terminals
• MTBF: Over 50,000 hours industrial grade reliability

3. Full Protection Functions (As Described)

Built-in triple safety protection circuit as your keyword highlighted:

1. Over Voltage Protection (OVP) Automatically shut down output when output voltage exceeds threshold to avoid burning PLC, sensors and controller boards.
2. Over Current Protection (OCP / Overload) 120% long-term overload tolerance; cut off output instantly under heavy overload to protect power loop and load devices.
3. Short Circuit Protection (SCP) Auto-recovery short-circuit protection; no permanent damage under continuous short circuit, resume normal operation after fault removal. Additional auxiliary protection: over-temperature thermal lockout, surge transient anti-interference protection

4. Mechanical & Environmental Parameters

• Mounting: Standard TS35 DIN rail quick clip installation
• Dimension: 194 mm × 113.6 mm × 138 mm
• Weight: ~0.5 kg
• Operating Temp: -25℃ ~ +70℃ (non-condensing)
• Storage Temp: -40℃ ~ +85℃
• Protection Class: IP20, indoor cabinet use
• Certifications: CE, UL 5085, RoHS industrial compliance

5. Key Advantages of Original ABB Unit

1. Original factory parts, full 12-month warranty, in stock for fast global shipment
2. Compact rugged housing, anti-vibration design for harsh factory environments
3. Support Modbus remote monitoring interface: real-time voltage/current/fault diagnosis via ABB control software
4. Parallel connection supported for power capacity expansion
5. Low electromagnetic interference (EMC compliant), stable power for I/O modules, transmitters, actuators

6. Typical Application Scenarios

• System 800xA DCS control cabinet power supply
• Oil & gas, chemical, metallurgy process automation
• Pharmaceutical, food & beverage production lines
• Water treatment, power plant auxiliary control systems
• Robot control, semiconductor intelligent factory equipment

English Sales Copy (For Inquiry/Listing Use)

ABB LXN1604-6 3BHL000986P7000 Original Industrial Power Module

Original ABB LXN1604-6 power supply unit, part number 3BHL000986P7000, designed for ABB System 800xA distributed control system. This 500W DIN rail switching power module adopts high-efficiency LLC resonant circuit, equipped with complete over voltage, over current and short circuit protection to safeguard your whole control system.
Universal 85-264V AC wide input fits global industrial grid standards, steady 24.7V DC 20A output supplies PLC, digital I/O modules, sensors and field actuators. With wide operating temperature range -25℃ to +70℃, reinforced isolation and anti-surge circuit, it performs reliably in severe workshop conditions.
Features remote Modbus communication for real-time power status monitoring and fault alarm. Original new genuine stock, 12-month quality warranty, worldwide fast delivery. Widely applied in oil & gas, chemical, metallurgy, water treatment and intelligent manufacturing process control projects. Built-in OVP/OCP/SCP triple protection prevents equipment burnout from abnormal circuit faults.
